Mini LED Downlight and Ease of Use
Nora Lighting introduces the M2 Series with a mini 2” aperture downlight or adjustable gimbal. Designed for easy installation, the M2 does not require a housing unit; it is outfitted with a prewired junction box that includes a quick connect to the LED fixture.
The M2 is IC- and air-tight rated for remodel and new construction applications and an optional new construction frame-in plate is available. The downlight has a deep 2.5” regression while the gimbal trim offers a maximum adjustability of 25°.
M2 delivers 400lm (6W) or 650lm (8W) and is offered in 2700K or 3000K at 90+CRI. Die-cast aluminum trims can be specified in matte black or matte powder white finish, along with an optional black or haze reflector for the downlight.
The M2 junction box includes four knockouts; snap-on cover; and quick- connects with 12” connector length. Two tension steel spring clips quickly and easily secure the luminaire to ceilings.
Optional accessories include quick connect extension cables in 4’ and 10’ lengths and new construction frame-in kits. M2 fixtures are cETLus damp location listed and 120V dimmable on Triac or ELV dimmers.
