Router: Automated Logic

Automated Logic
website | Company information

OptiFlex BACnet integrator is an advanced router/gateway for BACnetbased BAS networks. The router allows for large volumes of data derived from disparate BACnet equipment to easily interface with the WebCTRL system while also providing new network health diagnostic tools for system operators. The OptiFlex BACnet integrator features include:

• Simultaneous routing of BACnet communications across multiple network topologies including BACnet/IP and BACnet/Ethernet (up to 1GB), BACnet MSTP, and/or BACnet over ARCnet. Also provides additional flexibility by connecting two different BACnet networks;

• The ability to support and execute customized control programs built with Automated Logic’s EIKON graphical programming tool;

• Interfacing capabilities for communicating and managing third-party BACnet devices in a building;

• Diagnostic dashboards and trend graphs to help operators troubleshoot BACnet network communications inside of the WebCTRL BAS. Operators can visualize network statistics including logs/counters, transmit/receive activity, and network traffic latencies for the connected BACnet networks;

• Ability to capture BACnet network traffic either continuously or on-demand and save to a file for uploading into third-party network analysis tools.
